Street Light lamp 40-240W
Street Light lamp 40-240W
Street Light lamp 40-240W
Street Light lamp 40-240W
Street Light lamp 40-240W
Street Light lamp 40-240W
Street Light lamp 40-240W
Street Light lamp 40-240W
Street Light lamp 40-240W

Street Light lamp 40-240W

ASL11
Quantity:
DOWNLOAD MATERIALS
PARAMETRES
● SWIFT SERIES makes an affordable LED road lighting solution.
● The SWIFT SERIES street light family provides your city with a flexible lighting system which can be deployed anywhere in urban spaces, highways and rural areas.
● This model is an IP66 protection level, anti-collision level IK08, and IK09 anti-collision level can be customized.
● As it support changing the lens angle, it can achieve different light distribution types for different projects.
● This model is compatible with built-in light sensors, installation of NEMA bases and Zhaga bases, and fits with all external controllers, motion sensors, and external light sensors.








APPLICATION


ROADSRESIDENTIAL STREETSBRIDGESPARKING LOTAIRPORTPORT
STRUCTURE
Model Wattage Voltage
Efficiency
RA CCT Beam Angle PF IP IK
Material Of Shell
Material Of Lens
Pole diameter
(mm)
Dimension(mm)
ASL11-A 10-60W  AC85-305V 190LM/W  >70|80|90   2400K|2700K|3000K|
4000K|5000K|6500k
Type I | Type II | Type III
≥0.95
IP65|IP66| IP67
IK08|IK09| IK10
Aluminum (ADC12) +Tempered Glass
PMMA | PC
A:φ 50
BCDE:φ 60
530*220*135
ASL11-B  60W-80W  AC85-305V 190LM/W >70|80|90  2400K|2700K|3000K|
4000K|5000K|6500k
Type I | Type II | Type III ≥0.95 IP65|IP66| IP67 IK08|IK09| IK10 Aluminum (ADC12) +Tempered Glass PMMA | PC A:φ 50
BCDE:φ 60
600*245*155
ASL11-C 90W-120W AC85-305V 190LM/W >70|80|90  2400K|2700K|3000K|
4000K|5000K|6500k
Type I | Type II | Type III ≥0.95 IP65|IP66| IP67 IK08|IK09| IK10 Aluminum (ADC12) +Tempered Glass PMMA | PC A:φ 50
BCDE:φ 60
635*290*155
ASL11-D 130W-200W AC85-305V 190LM/W >70|80|90 2400K|2700K|3000K|
4000K|5000K|6500k
Type I | Type II | Type III ≥0.95 IP65|IP66| IP67 IK08|IK09| IK10 Aluminum (ADC12) +Tempered Glass PMMA | PC A:φ 50
BCDE:φ 60
685*290*155
ASL11-E 200W-240W AC85-305V 190LM/W >70|80|90 2400K|2700K|3000K|
4000K|5000K|6500k
Type I | Type II | Type III ≥0.95 IP65|IP66| IP67 IK08|IK09| IK10 Aluminum (ADC12) +Tempered Glass PMMA | PC A:φ 50
BCDE:φ 60
755*310*155
LIGHT DISTRIBUTION


Street Light lamp
Street Light lamp
Street Light lamp
Street Light lamp
Street Light lamp
Street Light lamp
SPECS SHEET
SWIFT150W(ASL11-D).pdf
Download PDF
ASL11 from Alite Lighting.pdf
Download PDF
