Outdoor Street Lighting Project 10-150W

• Versatile Luminaire Options:

A-Type: This variant incorporates four lenses, enabling a maximum power output of 50W.
B-Type: Featuring six lenses, it can accommodate a maximum power of 80W.
C-Type: With nine lenses, it can illuminate spaces using a maximum power of 120W, with an extended warranty option for 150W operation.
D-Type: Equipped with twelve lenses, this luminaire can deliver an impressive maximum power of 150W, with a potential for 180W under an extended warranty.

• Double Tool-Free Quick Disassembly:

Maintenance is a crucial aspect of any street lighting system. These innovative luminaires offer a double tool-free quick disassembly solution, ensuring effortless maintenance. This accessibility not only saves time but also reduces maintenance costs.

• Exceptional Waterproof and Impact Resistance:

These streetlights are designed to withstand the most severe environmental conditions. They boast an IP66 waterproof rating on the front and can endure impact levels ranging from IK08 to IK10. With various gasket options, they eliminate the issue of protruding glass, enhancing their durability.

• Superior Thermal Performance:

The LED streetlight housing is constructed using ADC12 aluminum die-casting, providing excellent heat dissipation properties. This ensures that the streetlights maintain optimal performance even during prolonged use.

• High-Quality Powder Coating:

The surface of the luminaire is coated with B-grade AkzoNobel powder paint, offering exceptional protection with a Neutral Salt Spray (NSS) resistance of ≥600 hours. This guarantees that the streetlights retain their aesthetic appeal over time.

• Compatibility and Expandability:

The enlarged driver compartment is designed to be fully compatible with brand drivers, as well as common accessories. This adaptability ensures that the streetlights can be easily upgraded or expanded as required.

• Adjustable Mounting Angle:

To cater to diverse lighting requirements, these streetlights come with adjustable mounting angles, offering angles of +10°, -15°, and 0-90°, enabling versatile installation.

• Tool-Free Quick Disconnection:

Incorporating terminal connectors for drivers and circuit breakers, these streetlights provide genuine double tool-free quick disconnection capabilities, making maintenance and upgrades straightforward and hassle-free.
