LED Garden Lamp 45-60W

AGL10
Quantity:
DOWNLOAD MATERIALS
PARAMETERS
AGL10 and AGL11 are very cost-effective garden lamp series. The design inspiration of its appearance comes from foreign lamp shell designers.
It has a small appearance and perfect integration with PC anti glare hood, reflecting the perfect industrial style. AGL10 and AGL11 are applicable to amusement parks, parks, wharves, industrial areas and other places. They
illuminate the environment and provide reliable performance.

AGL10 and AGL11 are made of ADC12. The waterproof grade has reached IP65. They can work in the working environment of -30 ℃ -50 ℃. They can be used in the natural environment for one year to ensure that they do not change color, and the corrosion resistance has reached WF1. AGL10 and AGL11 can use the conventional symmetric angle or the asymmetric angle like type3. The luminous efficiency is up to 100LM/W, providing reliable brightness lighting and power utilization.

APPLICATION

STRUCTURE

Product Model Wattage Input voltage
Luminous Efficacy
RA Color Temperature Beam Angle Power Factor IP Grade IK Grade
Material Of Shell
Material Of Lens
Dimension(mm)
AGL10 45W  AC100-277V 120LM/W  >70|80|90   2400K|2700K|3000K|4000K|5000K
90°
>0.9
IP65
IK08
Aluminum (ADC12)
PC|PMMA
AGL10:360*467
AGL11:440*467
AGL10  60W  AC100-277V 120LM/W >70|80|90 2400K|2700K|3000K|4000K|5000K 90° >0.9 IP65 IK08 Aluminum (ADC12)  PC|PMMA AGL10:360*467
AGL11:440*467
LIGHT DISTRIBUTION
45W
60W
SPECS SHEET
AGL10 AGL11 from Alite Lighting 2022 .pdf
Download PDF
2022 LED Street Lights catalogue from Alite.pdf
Download PDF
Spectrophotocolorimeter Test Report 45W.pdf
Download PDF
