Installation must be done by professional electricians.
Do NOT take apart the product. It may be dangerous.
Do NOT stare at the light with naked eyes. It is harmful to eyes.
For outdoor lighting, waterproof measurements must be done to the cable terminals.
WARRANTY:
All LED Street lights are warranted by the manufacturer to be free of defects in material and workmanship for 2 years.
Warranty becomes void if the products is modified, improperly installed or used, damaged by accident or neglect, or if any parts are improperly installed or replaced by the user.
During the period of warranty time, if some products of us fails during normal circumstances and applications or have any defects above defined, we shall at our own choice replace or repair the defective products at no charge. And the liability claims would NOT exceed the value of the product itself.
APPLICATION
ROADS
RESIDENTIAL STREETS
BRIDGES
PARKING LOT
AIRPORT
PORT
STRUCTURE
Model
Wattage
Voltage
Efficiency
RA
CCT
Beam Angle
PF
IP
IK
Material Of Shell
Material Of Lens
Dimension(mm)
ASL66Pro-A
50W
AC85-265V
110LM/W
>70|80
2400K|2700K|3000K
|4000K|5000K|6500K
80°|150°
>0.9
IP65
IK08
Aluminum (ADC12) +PC
PMMA | PC
375*140*51
ASL66Pro-B
100W
AC85-265V
110LM/W
>70|80
2400K|2700K|3000K
|4000K|5000K|6500K
80°|150°
>0.9
IP65
IK08
Aluminum (ADC12) +PC
PMMA | PC
480*172*59
ASL66Pro-C
150W
AC85-265V
110LM/W
>70|80
2400K|2700K|3000K
|4000K|5000K|6500K
80°|150°
>0.9
IP65
IK08
Aluminum (ADC12) +PC
PMMA | PC
565*176*69
ASL66Pro-D
200W
AC85-265V
110LM/W
>70|80
2400K|2700K|3000K
|4000K|5000K|6500K
80°|150°
>0.9
IP65
IK08
Aluminum (ADC12) +PC
PMMA | PC
630*279*69
LIGHT DISTRIBUTION
SPECS SHEET
