Best Led Flood Light 50-300W

PARAMETERS

ABOUT
AFL21

CAUTIONS:

1. Installation must be done by professional electricians.

2. Do NOT take apart the product. It may be dangerous.

3. Do NOT stare at the light with naked eyes. It is harmful to eyes.

4. For outdoor lighting, waterproof measurements must be done to the cable terminals.

WARRANTY:

1. All LED Street lights are warranted by the manufacturer to be free of defects in material and workmanship for 2 years.

2. Warranty becomes void if the products is modifified, improperly installed or used, damaged by accident or neglect, or if any parts are improperly installed or replaced by the user.

3. During the period of warranty time, if some products of us fails during normal circumstances and applications or have any defects above defifined, we shall at our own choice replace or repair the defective products at no charge. And the liability claims would NOT exceed the value of the product itself

Multiple Installation Methods

APPLICATION

STRUCTURE

Product Model	Wattage	Input voltage	Luminous Efficacy	RA	Color Temperature	Beam Angle	Power Factor	IP Grade	IK Grade	Material Of Shell	Dimension（mm）
AFL21-A	50W	AC85-265V	100Lm/W	>70	2400K \| 2700K \| 3000K \| 4000K 5000K \| 6500K	90°	>0.9	IP65	IK08	Aluminum (ADC12) +PC	*20217326*
AFL21-B	100W	AC85-265V	100Lm/W	>70	2400K \| 2700K \| 3000K \| 4000K 5000K \| 6500K	90°	>0.9	IP65	IK08	Aluminum (ADC12) +PC	*25422028*
AFL21-C	150W	AC85-265V	100Lm/W	>70	2400K \| 2700K \| 3000K \| 4000K 5000K \| 6500K	90°	>0.9	IP65	IK08	Aluminum (ADC12) +PC	*31326530*
AFL21-D	200W	AC85-265V	100Lm/W	>70	2400K \| 2700K \| 3000K \| 4000K 5000K \| 6500K	90°	>0.9	IP65	IK08	Aluminum (ADC12) +PC	*34229835*
AFL21-E	300W	AC85-265V	100Lm/W	>70	2400K \| 2700K \| 3000K \| 4000K 5000K \| 6500K	90°	>0.9	IP65	IK08	Aluminum (ADC12) +PC	*37632835*

LIGHT DISTRIBUTION

SPECS SHEET

AFL21 LED Floodlight from Alite Lighting-2022.pdf

Download PDF
