Outdoor Led Street Light 50-240W

ASL43
Quantity:
DOWNLOAD MATERIALS
PARAMETERS

ABOUT
 ASL43
ASL HUMMER SERIES are the series of Streetlight Fixtures that has been designed with LED transition in mind, whether to replace old HID lanterns, or Streetlight Fixtures on a new country, in places where you want citizens to feel safe. THE HUMMER Streetlight Fixtures offer simple benefits and reliable performance for roundabouts, crossings footpaths, industrial and civic areas. In addition, the linear driver design allows the ultra-thin appearance of Streetlight Fixtures , which gives a better wind resistance, with protection levels of IP65, and IK08. Moreover, the option of built-in light sensor is available that allows
the system to turn on the light at dark and turn it off at daylight auto-matically, making it perfect for all types of installation. Also there are external light sensors
●BRAND LED LAMP BEADS
HIGH BRIGHTNESS,HIGH COLOR RENDERING,LONG LIFESPAN
●BREAKER
THE DRIVER ROOM IS EQUIPPED WITH A SAFTY SWITCH TO ENSURE
THE SAFETY OF THE INSTALLATION AND MAINTENANCE PERSONNEL
outdoor led street light
PRODUCT DETAILS
outdoor led street light
APPLICATION
outdoor led street light
STRUCTURE
Product Model Wattage Input voltage
Luminous Efficacy
 RA Color Temperature Beam Angle Power Factor IP Grade IK Grade
Material Of Shell
Material Of Lens
Pole diameter
(mm)
 Dimension（mm）
ASL43-A 50W|60W  AC100-277V 140LM/W  >70|80|90   2400K|2700K|3000K|4000K|5000K
Type I | Type II | Type III
＞0.9
IP66
IK08
Aluminum (ADC12) +Optical Glass
PMMA | PC
A:φ 50 | 60
BCD:φ 60
520*210*110
ASL43-B  90W|100W  AC100-277V 140LM/W >70|80|90 2400K|2700K|3000K|4000K|5000K Type I | Type II | Type III ＞0.9 IP66 IK08 Aluminum (ADC12) +Optical Glass PMMA | PC A:φ 50 | 60
BCD:φ 60
650*255*135
ASL43-C 120W|150W AC100-277V 140LM/W >70|80|90 2400K|2700K|3000K|4000K|5000K Type I | Type II | Type III ＞0.9 IP66 IK08 Aluminum (ADC12) +Optical Glass PMMA | PC A:φ 50 | 60
BCD:φ 60
700*300*135
ASL43-D 200W|240W AC100-277V 140LM/W >70|80|90 2400K|2700K|3000K|4000K|5000K Type I | Type II | Type III ＞0.9 IP66 IK08 Aluminum (ADC12) +Optical Glass PMMA | PC A:φ 50 | 60
BCD:φ 60		 860*360*145
LIGHT DISTRIBUTION
outdoor led street light
outdoor led street light
outdoor led street light
outdoor led street light
 outdoor led street light
outdoor led street light
SPECS SHEET
ASL43 HUMMER from Alite Lighting 2022 .pdf
Download PDF
2022 LED Street Lights catalogue from Alite.pdf
Download PDF
HUMMER50W(ASL43-A).pdf
Download PDF
ASL43 Spectrophotocolorimeter Test Report 50W.pdf
Download PDF
