High Bay UFO Lights 100-200W

UFO19
UFO19 high bay ufo lights Adopting the cutting edge technology of IC controller in the industry,the key components have been mounted on the PCB With LEDs which is certified and proven to be comparable to the conventional driver solution.
Quantity:
DOWNLOAD MATERIALS
PARAMETERS
UFO19 is an economical industrial and mining lamp, you can use linear or DOB solution to meet the needs of different customers. UFO19 has three shell sizes, corresponding to 100W, 150W and 200W respectively.

The shell is made of die-cast aluminum of ADC12. The hollow-out structure makes the heat dissipation of the lamp body more excellent, and has the waterproof grade of IP65, applicable to the use of the environment. The surface of UFO19 is made of UV-resistant PC bead lens, which can effectively resist the corrosion of the lamp body by UV rays. The maximum number of beads of each lens can be put into 5 lamp beads, which can be adjusted according to the light efficiency and power requirements of customers, and the light-emitting angle of the lens is 90 °.
high bay ufo lights
APPLICATION

TUNNELSWAREHOUSEPARKING LOTSPORTS FACILITIESPORT
STRUCTURE
Product Model Wattage Input voltage
Luminous Efficacy
 RA Color Temperature Beam Angle Power Factor IP Grade IK Grade
Material Of Shell
Material Of Lens
 Dimension（mm）
UFO19-A 100W  AC100-240V 110LM/W  >70|80|90   2400K|2700K|3000K|4000K|5000K
90°
＞0.9
IP65
IK08
Aluminum (ADC12)
PC
Φ240*H55
UFO19-B  150W  AC100-240V 110LM/W >70|80|90 2400K|2700K|3000K|4000K|5000K 90° ＞0.9 IP65 IK08 Aluminum (ADC12)   PC
Φ290*H55
UFO19-C 200W AC100-240V 110LM/W >70|80|90 2400K|2700K|3000K|4000K|5000K 90° ＞0.9 IP65 IK08 Aluminum (ADC12)  PC
Φ320*H55
LIGHT DISTRIBUTION
100W
high bay ufo lights
150W
high bay ufo lights
200Whigh bay ufo lights
SPECS SHEET
UF19 LED High Bay Light.pdf
Download PDF
UFO19 SERIES.pdf
Download PDF
Spectrophotocolorimeter Test Report 150W.pdf
Download PDF
