Outdoor Street Light 50-200W

ASL46
Quantity:
DOWNLOAD MATERIALS
PARAMETERS
ASL46 SERIES OR THE SARDINE are the series of Streetlight Fixtures that has been designed with LED transition in mind, whether to replace old HID lanterns, or to put Streetlight Fixtures on a new country, in the places where you want citizens to feel safe.

THE SARDINE Streetlight Fixtures offer simple benefits and reliable performance for roundabouts, crossings footpaths, industrial and civic areas. In addition, the linear driver design allows the ultra-thin appearance of Streetlight Fixtures, which gives a better wind resistance, with protection levels of IP65, and IK08. Moreover the option of built-in light sensor is available that allows the system to turn on the light at dark and turn it off at daylight automatically, making it perfect for all types of installation.

● MILITARY SHELL
EFFICIENT HEAT DISSIPATION
● BREAKER
THE DRIVER ROOM IS EQUIPPED
WITH A SAFTY SWITCH TO ENSURE
THE SAFETY OF THE INSTALLATION
AND MAINTENANCE PERSONNEL
outdoor street light
PRODUCT DETAILS
outdoor street light
APPLICATION


ROADSRESIDENTIAL STREETSBRIDGESPARKING LOTAIRPORTPORT
STRUCTURE

Product Model Wattage Input voltage
Luminous Efficacy
RA Color Temperature Beam Angle Power Factor IP Grade IK Grade
Material Of Shell
Material Of Lens
Pole diameter
(mm)
Dimension(mm)
ASL46-A 50W|60W AC220-240V
 AC100-277V
110LM/W  >70|80|90   2400K|2700K|3000K|4000K|5000K
80°×130°
>0.9
IP65
IK08
Aluminum (ADC07)
PMMA | PC
A:50 | B:50\60 | C:60 | D:60
362*145*62
ASL46-B  80W100W|120W  AC220-240V
 AC100-277V
110LM/W >70|80|90 2400K|2700K|3000K|4000K|5000K 80°×130° >0.9 IP65 IK08 Aluminum (ADC07)  PMMA | PC A:50 | B:50\60 | C:60 | D:60
486*165*72
ASL46-C 150W AC220-240V
 AC100-277V
110LM/W >70|80|90 2400K|2700K|3000K|4000K|5000K 80°×130° >0.9 IP65 IK08 Aluminum (ADC07)  PMMA | PC A:50 | B:50\60 | C:60 | D:60
545*206*72
ASL46-D 180W|200W AC220-240V
 AC100-277V
110LM/W >70|80|90 2400K|2700K|3000K|4000K|5000K 80°×130° >0.9 IP65 IK08 Aluminum (ADC07)  PMMA | PC A:50 | B:50\60 | C:60 | D:60 623*235*72
LIGHT DISTRIBUTION

50W
outdoor street light
100W
outdoor street light
150W
outdoor street light
200W
outdoor street light
SPECS SHEET
ASL46 SARDINE from Alite Lighting 2022 .pdf
Download PDF
2022 LED Street Lights catalogue from Alite.pdf
Download PDF
SARDINE100W(ASL46-B).pdf
Download PDF
ASL46 Spectrophotocolorimeter Test Report.pdf
Download PDF
