Led Street Light 50 watt

ASL09
Quantity:
DOWNLOAD MATERIALS
PARAMETERS

ASL09 NEMO outdoor lighting SERIES are our best Commercial Led Street Lights which are easy to install and maintain has been designed to achieve 130Lm/w in normal operation conditionswith best streetlight cost ever seen   , meanwhile it comes in five different sizes that fits your need in , with perfect price and high performance. with a wide other options like The protection grade is IP65, the anti-collision grade is IK08, and it supports changing the lens angle to achieve different light distribution types  for different roads that allows you to make it fit in different applications and projects . As it Support the installation of built-in light sensors, installation of NEMA bases and Zhaga bases, compatible with all external controllers, motion sensors, and external light sensors.

Led Street Light 50 watt
APPLICATION


ROADSRESIDENTIAL STREETSBRIDGESPARKING LOTAIRPORTPORT
STRUCTURE

Product Model Wattage Input voltage
Luminous Efficacy
RA Color Temperature Beam Angle Power Factor IP Grade IK Grade
Material Of Shell
Material Of Lens
Pole diameter
(mm)
Dimension(mm)
ASL09-A 40W
 AC100-277VAC 50/60Hz
100LM/W  >70|80   2400K|2700K|3000K
|4000K|5000K
Type I | Type II | Type III
>0.95
IP66
IK08
Die-cast Aluminum + Optical Glass
PMMA | PC
φ 40
484*240*120
ASL09-B  60W
AC100-277VAC 50/60Hz
100LM/W >70|80 2400K|2700K|3000K
|4000K|5000K
Type I | Type II | Type III >0.95 IP66 IK08
Die-cast Aluminum + Optical Glass
PMMA | PC φ 50
530*240*120
ASL09-C 40W|60W|100W
AC100-277VAC 50/60Hz
100LM/W >70|80 2400K|2700K|3000K
|4000K|5000K
Type I | Type II | Type III >0.95 IP66 IK08
Die-cast Aluminum + Optical Glass
PMMA | PC φ 60
620*290*150
ASL09-D 120W|150W
AC100-277VAC 50/60Hz
100LM/W >70|80 2400K|2700K|3000K
|4000K|5000K
Type I | Type II | Type III >0.95 IP66 IK08
Die-cast Aluminum + Optical Glass
PMMA | PC φ 60
740*340*150
ASL09-E 180W|200W
AC100-277VAC 50/60Hz
100LM/W >70|80 2400K|2700K|3000K
|4000K|5000K
Type I | Type II | Type III >0.95 IP66 IK08
Die-cast Aluminum + Optical Glass
PMMA | PC φ 60
790*340*150
LIGHT DISTRIBUTION

50W
Led Street Light 50 watt
100W
Led Street Light 50 watt

150W
Led Street Light 50 watt
200W
Led Street Light 50 watt
SPECS SHEET
ASL09 Nemo series led street light.pdf
Download PDF
2022 LED Street Lights catalogue from Alite.pdf
Download PDF
NEMO SERIES 50W.pdf
Download PDF
Spectrophotocolorimeter Test Report 100W.pdf
Download PDF
ASL09 Installation Guide.pdf
Download PDF
