Intelligent Street Lighting 30-300W

ASL07
Quantity:
DOWNLOAD MATERIALS
PARAMETERS



ABOUT    ASL07

ASL07 SERIES offers the best LED road lighting solution for intelligent street
lighting to our clients for both pedestrian and vehicle road applications. It
offers 3 different housing sizes withs IP65, IK08 and a wide range of beam
optics to globally cater to different road design and conditions. It has been
designed to achieve better light uniformity distribution and maximum spacing
between poles even for the 80w LED street light, while ensuring perfect light
on the road. And this modal is compatible with built-in light sensors, installation
of NEMA bases and Zhaga bases, and fits all external controllers, motion sensors,
and external light sensors.
Intelligent Street Lighting

PRODUCT DETAILS
Intelligent Street Lighting
APPLICATION

Intelligent Street Lighting
STRUCTURE
Product Model Wattage Input voltage
Luminous Efficacy
RA Color Temperature Beam Angle Power Factor IP Grade IK Grade
Material Of Shell
Material Of Lens
Pole diameter
(mm)
Dimension(mm)
ASL07-A 10-80W  AC85-305V
AC450-480V
160LM/W  >70|80|90   2400K|2700K|3000K|
4000K|5000K|6500k
Type I | Type II | Type III
>0.95
IP65|IP66
IK08|IK09| IK10
Aluminum (ADC12) +Optical Glass
PMMA | PC
φ 60
580*240*140
ASL07-B  80W-150W  AC85-305V
AC450-480V
160LM/W >70|80|90  2400K|2700K|3000K|
4000K|5000K|6500k
Type I | Type II | Type III >0.95 IP65|IP66 IK08|IK09| IK10 Aluminum (ADC12) +Optical Glass PMMA | PC φ 60
740*344*145
ASL07-C 150W-300W AC85-305V
AC450-480V
160LM/W >70|80|90  2400K|2700K|3000K|
4000K|5000K|6500k
Type I | Type II | Type III >0.95 IP65|IP66 IK08|IK09| IK10 Aluminum (ADC12) +Optical Glass PMMA | PC φ 60
847*400*150
LIGHT DISTRIBUTION

Intelligent Street Lighting
Intelligent Street Lighting
Intelligent Street Lighting
Intelligent Street Lighting
Intelligent Street Lighting
Intelligent Street Lighting
SPECS SHEET
ASL07 HAWK SERIES from Alite Lighting.pdf
Download PDF
2022 LED Street Lights catalogue from Alite.pdf
Download PDF
HAWK150W(ASL07-B).pdf
Download PDF
