50-600W LED Light Reflector

PARAMETERS

Citizen well being and connectivity are key players in the game of differentiation among cities all over the world. And a way of achieving these goals is outdoor floodlight reflector light 150w; Lighting up outdoor floodlight reflector light 150w enhance the comfort. Security and overall safety of our rapidly growing urban environments.

This professional range of high brightness outdoor floodlight reflector light 150w luminaires AFL58 SERIES offers high quality standards at a very competitive price. Reliable, energy efficient and affordable, AFL58 SERIES outdoor floodlight reflector light 150w is the right solution for a wide range of outdoor applications, from building façades and retail stores to garden lighting.

Meanwhile this series outdoor floodlight reflector light 150w come with a simple choice for most area flood lighting applications, Saves time with easy installation of area flood lights and Long-lasting for excellent value.

APPLICATION


ROADS	TUNNELS	WAREHOUSE	PARKING LOT	SPORTS FACILITIES	PORT

STRUCTURE

Product Model	Wattage	Input voltage	Luminous Efficacy	RA	Color Temperature	Beam Angle	Power Factor	IP Grade	IK Grade	Material Of Shell	Dimension（mm）
AFL58-A	50W	AC85-265V	110LM/W	>70\|80\|90	2400K\|2700K\|3000K\|4000K\|5000K	30°	＞0.95	IP65	IK08	Aluminum (ADC12)	*3507540*
AFL58-B	100W	AC85-265V	110LM/W	>70\|80\|90	2400K\|2700K\|3000K\|4000K\|5000K	30°	＞0.95	IP65	IK08	Aluminum (ADC12)	*35015240*
AFL58-C	150W	AC85-265V	110LM/W	>70\|80\|90	2400K\|2700K\|3000K\|4000K\|5000K	30°	＞0.95	IP65	IK08	Aluminum (ADC12)	*35023240*
AFL58-D	200W	AC85-265V	110LM/W	>70\|80\|90	2400K\|2700K\|3000K\|4000K\|5000K	30°	＞0.95	IP65	IK08	Aluminum (ADC12)	*35031540*
AFL58-E	250W	AC85-265V	110LM/W	>70\|80\|90	2400K\|2700K\|3000K\|4000K\|5000K	30°	＞0.95	IP65	IK08	Aluminum (ADC12)	*48535075*
AFL58-F	300W	AC85-265V	110LM/W	>70\|80\|90	2400K\|2700K\|3000K\|4000K\|5000K	30°	＞0.95	IP65	IK08	Aluminum (ADC12)	*66023240*
AFL58-G	400W	AC85-265V	110LM/W	>70\|80\|90	2400K\|2700K\|3000K\|4000K\|5000K	30°	＞0.95	IP65	IK08	Aluminum (ADC12)	*66031540*
AFL58-H	500W	AC85-265V	110LM/W	>70\|80\|90	2400K\|2700K\|3000K\|4000K\|5000K	30°	＞0.95	IP65	IK08	Aluminum (ADC12)	*66545575*
AFL58-I	600W	AC85-265V	110LM/W	>70\|80\|90	2400K\|2700K\|3000K\|4000K\|5000K	30°	＞0.95	IP65	IK08	Aluminum (ADC12)	*66553575*

LIGHT DISTRIBUTION

SPECS SHEET

AFL58 SERIES.pdf

Download PDF

Spectrophotocolorimeter Test Report 200W.pdf

Download PDF

Reflector Light 50-600W
